AUTOPHIX E-SCAN ES620 Scanner Support OBD2 VW Protocols(including UDS Protocols)




69 reward points
Qty: Unit(s)
Related Download Files:

AUTOPHIX E-SCAN ES620 Scanner Support OBD2 VW Protocols(including UDS Protocols)

language: English, Germany, Polish, Czech


Autophix E-SCAN ES620 scanner is a strongest scan tool designed for user to detect ALL OBD II vehicles. It an ideal scanner that is made for ALL VW, Audi, Seat and Skoda series vehicle, and it can detect nearly 130 systems. It can support not ony the Controlled Area Network (TP-CAN) and New UDS protocol, but also ALL OBD II protocols. It enables the user to get into the VW, Audi, Seat and Skoda systems and get data quickly.

ES620 scanner is worthy of the best scanner! E-SCAN ES620 Feature:

1. Works on all after 1996 OBD II compliant US, European and Asian vehicles
2. Supports All VW Diagnositc protocols (KWP1281 KWP 2000 TP-CANBUS NEW UDS) and ALL OBD II protocols (CAN, J1850 PWM, J1850 VPW, ISO9141 and KWP2000).
3. Compatible Vehicles: VW/ Audi/ Seat/ Skoda/ Jetta/ Golf/ Beetle/ Touareg/ GTI/ Passat, etc.
4. Easily determines the cause of the "Check Engine Light ( MIL)"
5. Reads hard(memory)/pending(intermittent) and historic codes and show definitions
6. Clears codes and resets monitors
7. Reads live datastream
8. Views freeze frame data
9. I/M monitor readiness test
10. Displays live O2 sensor test data
11. Retrieves vehicle information (VIN, CIN and CVN).
12. Turns off the MIL Lights after clearing fault code.
13. Easily detects nearly 130 systems includes engine, ABS, Airbags, transmission, radio, climate control, instruments, immobilizer and so on.
14. Software upgradeable via internet.
15. CE, FCC, RoHS certificates E-SCAN ES620 Specification:
1. Display: 2.7 inches LCD display, Black-lit, 128 x 64 pixel display with contrast adjustment
2. Operating voltage: 8.0 to 18.0V power provided via vehicle battery
3. Operating temperature: 0°C to 60°C (32°F to 140°F)
4. Storage temperature: -20°C to 70°C (-4°F to 158°F)
5. External power: 8.0 to 18.0V power provided via vehicle battery
6. Weight: NW:0.48KG(1.06lb), GW:0.62KG(1.36lb)
7. Dimension: 166mm*88mm*30mm E-SCAN ES620


Package including:

1pc x ESCAN ES620 Scan Tool main unit
1pc x User's Manual
1pc x USB update cable
1pc x Durable Nylon Storage Case
